S P E C I F I C A T I O N S

High Frequency X-ray Generators

B A T T E R Y P O W E R E D

CONSTANT POTENTIAL POWER RATINGS

30 kW

40 kW

50 kW

RADIOGRAPHIC KVP RANGE IN 1 KVP STEPS ACCURACY	40 - 125/150 ±(1%)	40 - 125/150 ±(1%)	40 - 125/150 ±(1%)
MA RANGE & STATIONS ACCURACY	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320 ±(3%)	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320, 400 ±(3%)	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320, 400, 500 ±(3%)
POWER OUTPUT	320 mA @ 93 kVp 300 mA @ 100 kVp 250 mA @ 120 kVp 200 mA @ 150 kVp	400 mA @ 100 kVp 320 mA @ 125 kVp 250 mA @ 150 kVp	500 mA @ 100 kVp 400 mA @ 125 kVp 320 mA @ 150 kVp
EXPOSURE TIME RANGE ACCURACY	0.001 - 10 seconds ±(1%+0.1 ms)	0.001 - 10 seconds ±(1%+0.1 ms)	0.001 - 10 seconds ±(1%+0.1 ms)
MAS RANGE (*)	0.1 - 500 mAs (*)	0.1 - 500 mAs (*)	0.1 - 500 mAs (*)
HIGH VOLTAGE RIPPLE (TYP)	<1 kVp @ 100 kVp	<1 kVp @ 100 kVp	<1 kVp @ 100 kVp
AUTOMATIC EXPOSURE CONTROL (up to 4 Chambers)	Optional	Optional	Optional
Tomo	Optional	Optional	Optional
BUCKYS (2 UNITS STANDARD)	Optional up to 4	Optional up to 4	Optional up to 4
ANATOMICAL PROGRAMMING	Optional	Optional	Optional
UNINTERRUPTIBLE POWER SUPPLY (1)	Optional	Optional	Optional

FLUOROSCOPIC KVP RANGE IN 1 KVP STEPS ACCURACY	40 - 120 ±(1%)	40 - 120 ±(1%)	40 - 120 ±(1%)
FLUOROSCOPY FIXED PPS VARIBLE PPS (Optional)	at 50Hzat 60 Hz 50 PPS60 PPS 1, 2, 3, 6,1, 2, 4, 8, 12, 25, 3015, 30, 60	at 50Hzat 60 Hz 50 PPS60 PPS 1, 2, 3, 6,1, 2, 4, 8, 12, 25, 3015, 30, 60	at 50Hzat 60 Hz 50 PPS60 PPS 1, 2, 3, 6,1, 2, 4, 8, 12, 25, 3015, 30, 60
AUTOMATIC BRIGHTNESS CONTROL	Optional	Optional	Optional

3/2 POINT OPERATION CONSOLE	3 P. Standard / 2 P. Optional	3 P. Standard / 2 P. Optional	3 P. Standard / 2 P. Optional
LINE VOLTAGE RANGE AND PHASES	110-220-230 VAC - Single Phase	110-220-230 VAC - Single Phase	110-220-230 VAC - Single Phase
AUTOMATIC LINE COMPENSATION	± 15%	± 15%	± 15%
STORAGE CAPACITY	52,500 mAs @ 100 kV	127,500 mAs @ 100 kV	127,500 mAs @ 100 kV
MINIMUM POWER REQUIREMENTS ACCORDING TO IEC 601-2-7 = 2,200 W (X-RAY TUBE + GENERATOR)
(1) UNINTERRUPTIBLE POWER SUPPLY OPTION - (LINE POWER REQUIREMENT = 500 W (X-RAY TUBE + GENERATOR)

Specifications subject to change without notice
