H i g h F r e q u e n c y X - r a y G e n e r a t o r s

L I N E P O W E R E D - C A P A C I T O R S E R I E S

S P E C I F I C A T I O N S	1 Tube
MODEL	SHF 310-C/SHF 315-C	SHF 410-C/SHF 415-C	SHF 510-C/SHF 515-C

CONSTANT POTENTIAL POWER RATINGS

30 kW

40 kW

50 kW

RADIOGRAPHIC KVP RANGE IN 1 KVP STEPS ACCURACY	40 - 125/150 ±(1%)	40 - 125/150 ±(1%)	40 - 125/150 ±(1%)
MA RANGE & STATIONS ACCURACY	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320 ±(3%)	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320, 400 ±(3%)	10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320, 400, 500 ±(3%)
EXPOSURE TIME RANGE ACCURACY	0.001 - 10 seconds ±(1%+0.1 ms)	0.001 - 10 seconds ±(1%+0.1 ms)	0.001 - 10 seconds ±(1%+0.1 ms)
MAS RANGE (*)	0.1 - 500 mAs (*)	0.1 - 500 mAs (*)	0.1 - 500 mAs (*)
AUTOMATIC EXPOSURE CONTROL (up to 4 Chambers)	Optional	Optional	Optional
Tomo	Optional	Optional	Optional
CONNECTION FOR BUCKY (2 UNITS STANDARD)	Optional up to 4	Optional up to 4	Optional up to 4
ANATOMICAL PROGRAMMING (534 VIEWS)	Optional	Optional	Optional
UNINTERRUPTIBLE POWER SUPPLY (1)	Optional	Optional	Optional

3/2 POINT OPERATION CONSOLE	Standard	Standard	Standard
DIGITAL IMAGE SYSTEM INTERFACE	Optional	Optional	Optional
AUTOMATIC LINE COMPENSATION	from 90 to 264 VAC-1 ph	from 90 to 264 VAC-1ph	from 90 to 264 VAC-1ph
(*) Line Power Requirement Programmer	from 8 to 20 Amps	from 8 to 20 Amps	from 8 to 20 Amps
Recharge time between exposures: (for exposures at max. mAs)	as low as 3 seconds depending on available Line Power
Minimum Power Line Requirements According to IEC 601-2-7 = 2.000 W (peak-one second) (x-ray tube stator + generator)
